Nordwick made a four cylinder radial engine with cam instead of crankshaft. It was tested but never went into production.

-The cam was double, that is, forming an eight. It gave 200 HP at 1,500 rpm.

From Appendix 9: The cam mechanism instead of the crankshaft was also applied to another engine of this brand, but with eight cylinders.

Nordwick 8-cylinder radial engine schematic drawing
“8-cylinder radial, schematic drawing”

Engines of NORDWICK

Model: 4 cyl. radial

Arquitecture: 4-cylinder Radial
Cooling:
Total Displacement:
Bore / Stroke:
Power: 200 HP @ 1500 rpm
Weight:

Other details:
Model: 8 cyl. radial

Arquitecture: 8-cylinder Radial
Cooling:
Total Displacement:
Bore / Stroke:
Power:
Weight:

Other details:
