The Hart Engine Co. was based in Leeds. The engineer of the company, Mr. Redrup (see Redrup), built a 10-cylinder, 50 hp rotary engine, around 1910. (possibly with two rows of 5 cylinders),

-Later they built a 7-cylinder that gave 150 hp. A 9-cylinder 156 hp radial was built at Vickers Ltd.

-It is mentioned that there was another 9-cylinder rotary of similar power, 150 hp.

From Appendix 7: A 150 hp Hart engine was mounted on a Vickers FB.12, replacing another one of another brand that failed. This aircraft model installed several different engines.

Vickers with Hart radial engine
“Vickers with Hart radial engine” (PiP-fmr)

Engines of HART

Model: 10 cyl.

Arquitecture: 10-cylinder Rotary
Cooling: Air
Total Displacement:
Bore / Stroke:
Power: 50 HP
Weight:

Other details:
Model: 150 HP

Arquitecture: 7-cylinder Radial
Cooling:
Total Displacement:
Bore / Stroke:
Power: 150 HP
Weight:

Other details:
Model: 9 Cyl.

Arquitecture: 9-cylinder Radial
Cooling:
Total Displacement:
Bore / Stroke:
Power: 156 HP
Weight:

Other details:
