Angel Lascurain Orio was involved in responsible positions at TNCA (TNAC, sometimes) for the construction of engines and airplanes. (see also FAM).

-With regard to engines, there were three in common use in the army of that country: the "Trebol", which was a copy of a three-cylinder Anzani radial.

-The “Aztatl” with six radial cylinders, also licensed by Anzani and the SS Mexico with 10 cylinders in two radial rows of 5, also from Anzani.

Excerpt from the Lascurain rotary engine
“Excerpt from the Lascurain rotary engine”

-It is an engine designed for use in aviation. This study was carried out between 1927 and 1929. He built and patented it.

Engines of LASCURAIN

Model: Motor de aviación rotativo

Arquitecture: Rotary
Cooling:
Total Displacement:
Bore / Stroke:
Power:
Weight:

Other details:

The author of this edition of Aeroengines AtoZ, through Aeroteca, collaborated on Version 2 of this video, which is presented here.

To understand the operation of the connecting rods, the 1929 Continental R 670 single-cylinder engine was chosen.

A demonstration of Version 3, improved at the author's suggestion, is also available on YouTube at a later date. This version shows bronze valve guides, improved valve spring movement, and the split crankshaft counterweights and front bearing balls also move.

The design is from Juan Soler, Sant Cugat, Barcelona

Below we show a flash of version 3

Counting also with the coloboration of JMC of Enginys Mecanics in Mataro, Barcelona
