Charles Keene of Los Angeles, California made a small aeronautical, three-cylinder radial engine running on Diesel.

Charles Keene and his engine
“Charles Keene and his engine”

-It delivered 6 hp with an ingenious fuel injection system in the cylinder and a compression ratio of 16 to 1.

-Although it was designed for small planes, there were plans to build larger models on that base.

From Appendix 6: Some more information about the small Charles Keene aero engine in Los Angeles. Running on Diesel.

Charles Keene showing engine details
“Charles showing engine details”

-It has three radial cylinders and uses the two stroke cycle. The engine gave 6.3 hp at 2,000 rpm.

Engines of KEENE

Model: 3 cyl. radial

Arquitecture: 2-stroke3-cylinder Radial
Cooling:
Total Displacement:
Bore / Stroke:
Power: 6 HP @ 2000 rpm
Weight:

Other details:
